16mm C VIS-NIR Series Fixed Focal Length Lens Long-wave infrared lens

Informacion basica

Place of Origin:	Shenzhen, China
Nombre de la marca:	Octavia
Model Number:	MR-C1602BD-118

Cantidad de orden mínima:	1
Precio:	$620USD/pc
Detalles de empaquetado:	Paquete por defecto
Tiempo de entrega:	5-8 días laborables
Condiciones de pago:	T/T
Capacidad de la fuente:	999pcs

Contactar ahora

Material:	Vidrio óptico de alta calidad	BFL:	13 mm
Mod:	los 0.1m	Revestimiento:	Revestimiento antirreflectante
Tamaño del tornillo del filtro:	M28.5*0.5	Tipo de montaje:	Contrando C
Tamaño de imagen:	1/2''(6,48*5,16 mm)	Rango de temperatura:	-10~50°C

16mm C VIS-NIR Series Fixed Focal Length Lens Long-wave infrared lens

Long-wave infrared lens
VISIBLE INFRARED LENS
This long-wave infrared lens is specially designed for SWIR chips IMX990/IMX991, covering visible light + near-infrared bands (400.1700nm)

This long-wave infrared lens uses ultra-low dispersion glass, which fully corrects focus shifts over an ultra-wide wavelength range
High transmittance, high uniformity
It is widely used in industrial sorting, color difference detection, food testing, medical, and other fields

Specification
Model	MR-C1602BD-118	Mount	C
Focal Length	16mm	Resolution	8.0MP
Sensor Size	1/2''(6.48*5.16mm)	Type	Long-wave infrared lens
Aperture	F1.8-16	Dimension	Φ33.5*44.65mm
MOD	10cm	Operating Temperature	-10°C -- +50°C
Angle of View	22.44(H)17.98(V)28.14(D)	BFL	13mm
Remark	Metal Lens
